CRI0-9063 NI CompactRIO Chassis/Controller

Description CRI0-9063 NI CompactRIO Chassis/Controller Product Dimensions： Product Description (Detailed Explanation) The cRIO-9063 is a cost-effective, “all-in-one” chassis that integrates a dual-core processor, a reconfigurable FPGA, and 4 slots for C Series I/O modules. Unlike traditional PLCs, the cRIO-9063 utilizes a Zynq-7000 All Programmable SoC (System on Chip) architecture. This architecture bridges the gap between a high-level processor running NI Linux Real-Time and a Xilinx Artix-7 FPGA. This allows engineers to perform complex floating-point calculations on the CPU while managing high-speed, nanosecond-level timing and triggering on the FPGA. Product Parameters (Technical Specifications) Parameter Category Specification Processor ARM Cortex-A9 Dual-Core (667 MHz) Operating System NI Linux Real-Time FPGA Xilinx Artix-7 (A7) Number of Slots 4 Slots for C Series Modules Nonvolatile Memory 512 MB (Storage) System Memory (RAM) 256 MB (DDR3) Network Interfaces 2 x 10/100/1000 Mbps Gigabit Ethernet Ports USB Support 1 x USB Hi-Speed Host Port Supply Voltage 9 V to 30 V DC Operating Temp -20 °C to 55 °C Product Advantages (Key Benefits) Embedded Intelligence: Runs a robust Linux-based Real-Time OS, allowing for advanced libraries, web services, and file management. Custom Hardware Performance: The integrated FPGA allows users to implement custom hardware-timed logic, high-speed digital filtering, and synchronous sampling that exceeds standard PLC capabilities. Ruggedized for Industry: Designed to withstand 50 g shock and 5 g vibration, making it suitable for deployment in extreme industrial environments. Gigabit Ethernet Redundancy: Dual Ethernet ports allow for separate network segments (e.g., one for the corporate LAN and one for a deterministic I/O network). Vast Module Ecosystem: Compatible with over 100 NI and 3rd-party C Series modules for analog, digital, motion, and specialized communication (CAN, PROFINET, etc.). Precautions (Important Notes) Power Supply Quality: Use a regulated 24V DC power supply. Transient voltage spikes can damage the SoC; ensure the system is properly fused. Grounding: The chassis must be grounded to a metal DIN rail or backplane using the grounding screw to minimize electromagnetic interference (EMI). Thermal Management: When using high-power modules in all 4 slots, ensure adequate vertical spacing in the enclosure to allow for natural convection cooling. Software Compatibility: Requires LabVIEW 2013 or later and the LabVIEW Real-Time and FPGA modules for full programming capability. Product Applications (Typical Use Cases) The cRIO-9063 is ideal for applications where precision timing and complex data processing converge: Machine Condition Monitoring: High-speed vibration analysis and predictive maintenance for rotating machinery. Smart Grid Control: Phasor measurement units (PMUs) and power quality monitoring in electrical substations. Industrial Internet of Things (IIoT): Serving as an edge gateway that processes raw sensor data locally before sending summarized analytics to the cloud. Embedded Control: Controlling hydraulic test stands or complex motion systems that require sub-millisecond loop rates. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： ACCURAY 8-061588-002 ADEMCO ADR1600E ADTEC AX-1000-AMII ACCURAY QA-3-017948-003 ADEMCO HRM60N500 ADTRAN 4200663L1 ACCURAY 086370-001 ADEMCO VISTA-250FBP Advanced ICP-16L ACCURAY 086158-004 ADEPT Adept 101 ADVANCED DUO-I8030NM ACCURAY 085221-001 ADEPT AWCII 040 ADVANCED 9R918W3 ACCURAY 061552-001 ADEPT EJI90340-40000 ADVANCED SB1391-C-R-C-A Accu-Sort BoxPC-126M ADEPT SCARA 550 Advanced MN3150272-006 ACME TA-1-81008 ADEPT 10330-11350 Advantech PPC-105T-ABAR ACME TA-1-32406 ADEPT 10332-12350 Advantech FPM-3171G-XCE ACME TA-1-81306 ADEPT ASSY 10350-00100 Advantech WOP-2100T-N2AE ACME T-1-53011 ADEPT ADEPT AWCII 040 ADVANTEST R3265A ACME TA-2-81003 ADEPT AWCII-040 ADVANTEST BLF-022828 ACC-BOARD Acquisition AL81G ADEPT 90402-40013/XY-HRS013-S1B1-AD ADVANTEST BLG-022829 ACS ACS-0400-PS ADEPT 90402-40013 ADVANTEST R6244 ACS SB1381-B-E-R-A-PM2 ADEPT 90400-20055/XY-HRS-055M201 Advantest D3185A ACS SB1381-C-E-R-A ADEPT 90400-02100-EXTB01AD AE RAPID-F ACS SB214ND-F-9 ADEPT 90400-70030 AEG 41-94384 ACS MOTION CONTROL HSSI-I016 ADEPT 90400-71031 AEG M907-122 ACT TCS-SRME-6210-CD-RTM ADEPT 10330-11350 AEG DEP220 ACTION AIOI8100 ADIXEN FM36122 AEG DTA200 ACTUS POWER NPSA-TMTA-222 ADP ADP-1 AEG DTA201 ACUITY 002-PV900 ADRIVE E642B-MGB-K-01 AEG PC-A984-145 ACUITY 010-PV9040 ADTEC 3000III AEG MM-PM22-200 ADC FPL-72RP0W-1448B ADTEC AXR-2000III AEG MM-PM21400C ADDI-DATA APCI-1710 ADTEC AX-2000EUII-N AEG MM-PM21-400 AEG AS-P892-000 AEG M135-H60A-OYOY-G3 AEG PC-E984-381 AEG M344-MKOA-4001 Aerotech U100M-A-40-F5 AEG MM-PM22-300 AEG CGC13-TB AFE DP320T-BC AGIE MJG-2129 AGILENT G2630-66015
