PXIE-8135 NI Core i7 Embedded Controller for PXIe

Description PXIE-8135 NI Core i7 Embedded Controller for PXIe Product Dimensions： Product Description (Detailed Explanation) The PXIe-8135 is a PC-in-a-slot that occupies the system controller slot (Slot 1) of a PXI Express chassis. It features a quad-core Intel Core i7-3610QE processor, which utilizes Hyper-Threading technology to provide eight logical cores. What sets this controller apart is its high-bandwidth backplane interface. It utilizes PCI Express Gen 2 technology to deliver up to 4 GB/s of dedicated system bandwidth and 2 GB/s of slot bandwidth. This makes it ideal for data-intensive applications like high-speed RF record and playback, structural test, and large-scale data acquisition. Product Parameters (Technical Specifications) Parameter Category Specification Processor Intel Core i7-3610QE (2.3 GHz base, 3.3 GHz Turbo) Cores/Threads 4 Cores / 8 Threads Standard Memory 4 GB (up to 16 GB DDR3-1600 MHz) System Bandwidth 4 GB/s Slot Bandwidth 2 GB/s Storage 250 GB (or larger) SATA HDD or SSD I/O Ports 2 x DisplayPort, 2 x USB 3.0, 4 x USB 2.0, 2 x Gigabit Ethernet Operating System Windows 7/10 or NI LabVIEW Real-Time Slot Occupancy 1 System Slot (PXI Express) Product Advantages (Key Benefits) High Processing Density: The quad-core i7 processor allows for heavy multi-threaded calculations, such as Fast Fourier Transforms (FFT) or complex PID loops, to be performed in real-time. Massive Throughput: The 4 GB/s system bandwidth ensures that data can be streamed from multiple high-speed digitizers or modules to the controller’s memory without bottlenecks. Peripheral Connectivity: With built-in USB 3.0 and dual Gigabit Ethernet, it easily integrates with external instruments, cameras, and corporate networks. Rugged Design: Unlike a standard laptop or desktop, the PXIe-8135 is designed for the high vibration and wide temperature ranges found in industrial and military environments. Dual-Display Support: The dual DisplayPort outputs allow for high-resolution multi-monitor setups for complex HMI and data visualization. Precautions (Important Notes) Slot Compatibility: This is a PXI Express controller. It must be installed in the system controller slot (usually the leftmost slot) of a PXIe or PXI/PXIe hybrid chassis. It will not fit in a standard PXI (non-Express) chassis. Cooling: The PXIe-8135 relies on the chassis fans for cooling. Ensure the chassis filters are clean and that there is sufficient clearance at the air intake and exhaust. Memory Upgrades: If upgrading RAM, use NI-certified memory modules. Non-standard RAM may cause timing issues with the high-speed backplane. Software Environment: Ensure that NI PXI Platform Services and the correct drivers (e.g., NI-DAQmx, NI-VISA) are installed to recognize the modules within the chassis. Product Applications (Typical Use Cases) Automated Test Equipment (ATE): Serving as the central controller for production line testing of semiconductors, automotive electronics, and consumer devices. RF and Wireless Test: High-speed streaming of IQ data for 5G, Wi-Fi, and radar signal analysis when paired with NI vector signal transceivers (VST). Hardware-in-the-Loop (HIL): Simulating real-world environments for aerospace or automotive ECU testing using LabVIEW Real-Time. Structural Health Monitoring: Synchronizing and processing hundreds of strain gauge and vibration sensors in civil engineering or aerospace fatigue testing. High-Energy Physics: Data acquisition and control in research facilities requiring nanosecond-level synchronization and massive data logging. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： ACCURAY 8-061588-002 ADEMCO ADR1600E ADTEC AX-1000-AMII ACCURAY QA-3-017948-003 ADEMCO HRM60N500 ADTRAN 4200663L1 ACCURAY 086370-001 ADEMCO VISTA-250FBP Advanced ICP-16L ACCURAY 086158-004 ADEPT Adept 101 ADVANCED DUO-I8030NM ACCURAY 085221-001 ADEPT AWCII 040 ADVANCED 9R918W3 ACCURAY 061552-001 ADEPT EJI90340-40000 ADVANCED SB1391-C-R-C-A Accu-Sort BoxPC-126M ADEPT SCARA 550 Advanced MN3150272-006 ACME TA-1-81008 ADEPT 10330-11350 Advantech PPC-105T-ABAR ACME TA-1-32406 ADEPT 10332-12350 Advantech FPM-3171G-XCE ACME TA-1-81306 ADEPT ASSY 10350-00100 Advantech WOP-2100T-N2AE ACME T-1-53011 ADEPT ADEPT AWCII 040 ADVANTEST R3265A ACME TA-2-81003 ADEPT AWCII-040 ADVANTEST BLF-022828 ACC-BOARD Acquisition AL81G ADEPT 90402-40013/XY-HRS013-S1B1-AD ADVANTEST BLG-022829 ACS ACS-0400-PS ADEPT 90402-40013 ADVANTEST R6244 ACS SB1381-B-E-R-A-PM2 ADEPT 90400-20055/XY-HRS-055M201 Advantest D3185A ACS SB1381-C-E-R-A ADEPT 90400-02100-EXTB01AD AE RAPID-F ACS SB214ND-F-9 ADEPT 90400-70030 AEG 41-94384 ACS MOTION CONTROL HSSI-I016 ADEPT 90400-71031 AEG M907-122 ACT TCS-SRME-6210-CD-RTM ADEPT 10330-11350 AEG DEP220 ACTION AIOI8100 ADIXEN FM36122 AEG DTA200 ACTUS POWER NPSA-TMTA-222 ADP ADP-1 AEG DTA201 ACUITY 002-PV900 ADRIVE E642B-MGB-K-01 AEG PC-A984-145 ACUITY 010-PV9040 ADTEC 3000III AEG MM-PM22-200 ADC FPL-72RP0W-1448B ADTEC AXR-2000III AEG MM-PM21400C ADDI-DATA APCI-1710 ADTEC AX-2000EUII-N AEG MM-PM21-400 AEG AS-P892-000 AEG M135-H60A-OYOY-G3 AEG PC-E984-381 AEG M344-MKOA-4001 Aerotech U100M-A-40-F5 AEG MM-PM22-300 AEG CGC13-TB AFE DP320T-BC AGIE MJG-2129 AGILENT G2630-66015
