PXIE-6363 NI X Series Multifunction DAQ Module

Description PXIE-6363 NI X Series Multifunction DAQ Module Product Dimensions： Product Description (Detailed Explanation) The PXIe-6363 is designed to be the “Swiss Army Knife” of an automated test system. It combines analog input (AI), analog output (AO), digital I/O (DIO), and hardware counters into a single-slot PXI Express module. Built on the NI-STC3 timing and synchronization technology, it provides independent timing engines for different I/O types, allowing for multi-rate sampling. Its integration with the PXI Express backplane ensures low-latency communication and high-bandwidth data transfer to the host controller, making it suitable for hardware-in-the-loop (HIL) simulations and high-speed control loops. Product Parameters (Technical Specifications) Parameter Category Specification Analog Inputs (AI) 32 Single-Ended / 16 Differential Channels AI Resolution 16-bit AI Sample Rate 2.0 MS/s (Single Channel), 1.0 MS/s (Multichannel) Input Range ±0.1 V, ±0.2 V, ±0.5 V, ±1 V, ±2 V, ±5 V, ±10 V Analog Outputs (AO) 4 Channels, 16-bit, 2.86 MS/s Digital I/O (DIO) 48 Total (32 Hardware-Timed up to 10 MHz) Counters/Timers 4 Channels, 32-bit resolution Bus Interface PXI Express (x1 Gen 1) Connection Type 2 x 68-pin VHDCI connectors Product Advantages (Key Benefits) High Throughput: The PXI Express interface offers significantly higher bandwidth than standard PCI/PXI, reducing data bottlenecks during high-speed streaming. X Series Timing: Features NI-STC3 technology, which provides 4 advanced counters, a 100 MHz timebase, and independent timing engines for AI, AO, and DIO. Multi-Function Integration: Replaces multiple specialized cards by providing high-quality analog and digital capabilities in one module, saving rack space and cost. Seamless Software Support: Fully compatible with LabVIEW, MATLAB, and C#/.NET via the NI-DAQmx driver, which simplifies programming with measurement-ready functions. Advanced Triggering: Can be synchronized with other PXI modules via the backplane trigger bus to achieve sub-microsecond alignment between different hardware units. Precautions (Important Notes) Signal Connection: Due to the high density of the 68-pin VHDCI connectors, it is highly recommended to use shielded cables (e.g., SHC68-68-EPM) and terminal blocks (e.g., SCB-68A) to minimize noise and crosstalk. Grounding: Ensure a common ground between the PXI chassis and the external signal sources to avoid ground loop errors or potential damage to the high-impedance inputs. Power Budget: High-performance DAQ modules consume significant power. Verify that your PXIe chassis (e.g., PXIe-1073 or PXIe-1078) has sufficient cooling and power headroom for all installed cards. Calibration: For high-accuracy applications, the module should be calibrated annually. Check the onboard self-calibration features in NI-DAQmx to compensate for temperature-related drifts. Product Applications (Typical Use Cases) Automated Test Equipment (ATE): Functional testing of electronic components, circuit boards, and consumer electronics in production lines. Hardware-in-the-Loop (HIL): Simulating real-world sensors and actuators to test Embedded Control Units (ECUs) in automotive or aerospace industries. Structural Health Monitoring: Recording high-speed vibration and strain gauge data from bridges, aircraft wings, or mechanical turbines. Control System Prototyping: Implementing complex PID control loops or custom signal modulation for laboratory research and development. Acoustic and Noise Analysis: Capturing and generating audio-frequency signals for microphone and speaker characterization. Shipping Port: Xiamen, China Payment: Bank of Chicago, Bank of Singapore Express cooperation: fedex, DHL, UPS and your express account Service: Professional Sales provides 24 hours /7 days online service Please make an inquiry for more models： ACCURAY 8-061588-002 ADEMCO ADR1600E ADTEC AX-1000-AMII ACCURAY QA-3-017948-003 ADEMCO HRM60N500 ADTRAN 4200663L1 ACCURAY 086370-001 ADEMCO VISTA-250FBP Advanced ICP-16L ACCURAY 086158-004 ADEPT Adept 101 ADVANCED DUO-I8030NM ACCURAY 085221-001 ADEPT AWCII 040 ADVANCED 9R918W3 ACCURAY 061552-001 ADEPT EJI90340-40000 ADVANCED SB1391-C-R-C-A Accu-Sort BoxPC-126M ADEPT SCARA 550 Advanced MN3150272-006 ACME TA-1-81008 ADEPT 10330-11350 Advantech PPC-105T-ABAR ACME TA-1-32406 ADEPT 10332-12350 Advantech FPM-3171G-XCE ACME TA-1-81306 ADEPT ASSY 10350-00100 Advantech WOP-2100T-N2AE ACME T-1-53011 ADEPT ADEPT AWCII 040 ADVANTEST R3265A ACME TA-2-81003 ADEPT AWCII-040 ADVANTEST BLF-022828 ACC-BOARD Acquisition AL81G ADEPT 90402-40013/XY-HRS013-S1B1-AD ADVANTEST BLG-022829 ACS ACS-0400-PS ADEPT 90402-40013 ADVANTEST R6244 ACS SB1381-B-E-R-A-PM2 ADEPT 90400-20055/XY-HRS-055M201 Advantest D3185A ACS SB1381-C-E-R-A ADEPT 90400-02100-EXTB01AD AE RAPID-F ACS SB214ND-F-9 ADEPT 90400-70030 AEG 41-94384 ACS MOTION CONTROL HSSI-I016 ADEPT 90400-71031 AEG M907-122 ACT TCS-SRME-6210-CD-RTM ADEPT 10330-11350 AEG DEP220 ACTION AIOI8100 ADIXEN FM36122 AEG DTA200 ACTUS POWER NPSA-TMTA-222 ADP ADP-1 AEG DTA201 ACUITY 002-PV900 ADRIVE E642B-MGB-K-01 AEG PC-A984-145 ACUITY 010-PV9040 ADTEC 3000III AEG MM-PM22-200 ADC FPL-72RP0W-1448B ADTEC AXR-2000III AEG MM-PM21400C ADDI-DATA APCI-1710 ADTEC AX-2000EUII-N AEG MM-PM21-400 AEG AS-P892-000 AEG M135-H60A-OYOY-G3 AEG PC-E984-381 AEG M344-MKOA-4001 Aerotech U100M-A-40-F5 AEG MM-PM22-300 AEG CGC13-TB AFE DP320T-BC AGIE MJG-2129 AGILENT G2630-66015
